- Brand: X-Security
- Product Code: XS-XVR6216AS-2AI
- Availability: In Stock
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.
To order and view prices you must register or login.
5n1 X-Security Video Recorder - 16 CH HDTVI/HDCVI/AHD/CVBS (5Mpx) + 8 IP (6Mpx) - 2 CH Face Recognition | perimeter protection - 16 CH Recognition of humans and vehicles - 5M-N recording resolution - Alarms | Audio All-over-Coax
- X-Security
- XVR 5n1
- 16 CH video HDTVI/HDCVI/AHD/CVBS / 24 IP / 4 CH audio
- H.265+/H.265
- 2CH Face Recognition
- 2 CH Perimeter Protection
- False alarm filter for vehicles and people (12 Ch)
- Resolution per channel: 5M-N(1~10fps) 4M-N/1080p (1~15FPS) 1080N/720P/960H/D1/CIF (1fps–25/30fps)
- PTZ control (RS485)
- Alarm
- Two-way audio All-over-Coax
- HDMI Full HD and VGA output
- Mouse
- Space for 2 HDD
- POS
Software
EN | ZIP | 15.80 MB | ||
EN, ES, FR, IT, PT, DE | ZIP | 102.48 MB | ||
EN | ZIP | 143.51 MB | ||
EN | ZIP | 92.47 MB |
Article | |
Brand | X-SECURITY |
Product Code | XS-XVR6216AS-2AI |
General | |
Internal storage | 2 SATA HDD up to 10TB (not included) |
Video/audio compression | H.265+/H.265/H.264+/H.264 / G.711u |
Video format | HDTVI / HDCVI / AHD / CVBS / IP |
Hybrid configuration | Up to 24 IP Channels (5M-N), replacing all BNC channels |
Recording method | Manual, scheduled, motion detection, alarm, stop |
Remote Access | Browser, mobile phone APP or PSS software |
Two-way Audio | Reusing audio input/output |
Video inputs | 16 BNC Channels (HDTVI / HDCVI / AHD / CVBS) |
Weight | 1.8 Kg |
Communication | RS485 (PTZ) /2 x USB (Mouse and backup) / RJ45 10/100/1000 (Ethernet) |
Video outputs | 1 HDMI 4K, 1 VGA |
Bandwidth | 128 Mbps |
Display Resolution | HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
Audio | 4 in / 1 out RCA |
Power | DC 12V / 4A |
Extra Stream coding | D1/CIF (1fps–15fps) |
Smart Features | P2P function | POS function | Alarm/audio/update via Coaxial (All-over-Coax) |
Recording resolution | 5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF |
Main Stream coding | 5M-N (1fps–10fps); 4M-N/1080P (1fps–15fps); 1080N/720P/960H/D1/CIF (1fps–25/30fps) |
Dimensions | 288 (H) x 375 (W) x 53 (D) mm |
video analysis | IVS: Line Crossing | Area Intrusion | Abandoned object | face detection IP mode, Facial recognition and IVS cannot be activated at the same time |
Simultaneous multifunction | Pentaplex: Direct, Recording, Playback, Backup and Remote Access |
Alarm | 16 input / 3 relay |
SMD+ | Intelligent motion detection, up to 16 channels capable of classifying targets between humans and vehicles |
Backup | USB / Network |
