DVR 5n1 X-Security - 8 CH HDTVI/HDCVI/AHD/CVBS(5Mpx) + 4 IP(6Mpx) - Audio over coaxial - 5M-N (10FPS) Recording Resolution - 1 CH facial recognition - 1 CH Human and vehicle recognition
  • Brand: X-Security
  • Product Code: XS-XVR6108AS-1FACE
  • Availability: In Stock
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.

DVR 5n1 X-Security - 8 CH HDTVI/HDCVI/AHD/CVBS(5Mpx) + 4 IP(6Mpx) - Audio over coaxial - 5M-N (10FPS) Recording Resolution - 1 CH facial recognition - 1 CH Human and vehicle recognition


  • X-Security
  • XVR 5n1
  • 8 CH video HDTVI/HDCVI/AHD/CVBS / 8+4 IP / 1 CH audio
  • H.265+/H.265/H.264+/H.264
  • Recording resolution 5M-N (10FPS) or 4M-N/1080p (15FPS) or 1080N/720P (25/30FPS) [%VAR%]
  • PTZ Control (RS485/Coaxial)
  • Audio
  • HDMI Full HD, VGA & CVBS Outputs
  • 1 CH comparison of face
  • Human and Vehicle Recognition (Available for 4 CH coaxial video)
  • Mouse
  • 2 USB Ports
  • Space for 1 HDD
  • Compact size



  • DVR 5 in 1 X-Security
  • Mouse
  • 12VDC Power supply

alt


Article
Brand X-SECURITY
Product Code XS-XVR6108AS-1FACE
General
Video format HDTVI / HDCVI / AHD / CVBS / IP
Hybrid configuration Up to 12 IP Channels (6Mpx), replacing all the BNC channels
Recording method Manual, programmed, motion detection, alarm
Remote Access Web browser (ActiveX), mobile phone application or PSS software
Video inputs 8 Channels BNC (HDTVI / HDCVI / AHD / CVBS)
Weight 1 Kg
Communication RS485 (PTZ) /2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet)
Video outputs 1 HDMI 1080p, 1 VGA
Audio inputs 1 Channel RCA
Display Resolution 1920x1080, 1280x1024, 1280x720
Video / audio compression H.265+/H.265/H.264+/H.264
Audio outputs 1 Channel RCA
Total bandwidth 64 Mbps
Bidirectional audio Reusing the audio input/output
Power DC 12V / 2A
Extra Stream coding D1 / CIF (1~15 FPS)
Intelligent motion detection 1 channel capable of classifying targets between humans and vehicles
Recording resolution 5 M-N, 4 M-N,1080p, 1080N, 720p, 960H, D1, CIF
Main Stream coding 5M-N(10 FPS); 4M-N/1080p(15 FPS); 1080N / 720p / 960H / D1 / CIF (25/30 FPS)
Dimensions 47.6 (H) x 260 (W) x 237.5 (D) mm
video analysis IVS: Tripwire | Area intrusion | Abandoned object | Face detection
Internal memory 1 SATA HDD 3.5" of up to 10 TB (not included)
Simultaneous multifunction Pentaplex: Live, Recording, Playback, Backup and Remote Access
Alarm No
Facial recognition 1 live analogue face comparison channel
Backup USB / Network
