- Brand: YLI Electronic
- Product Code: YB-500I-LED
- Availability: In Stock
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.
To order and view prices you must register or login.
Electromechanical safety lock - Fail Safe (NC) opening mode - Retention force 1000 Kg - Door status sensor - Programmable self-closing - Selectable opening time
- Electromechanical Security Piston Lock surface
- NC Normally Closed (Fail Safe)
- Timer with Delay of 0/3/6/9 seconds
- Open door signal
- Applicable in Fire protection systems
- Installation in Wooden, Metal, Glass and Fire doors
- 12 VDC
- Made of stainless steel
- Lock
- Electromagnetic strike with sensor
- Installation material (covers, hardware, jigs)
- User instructions
| Article | |
| Brand | YLI Electronic |
| Product Code | YB-500I-LED |
| General | |
| Opening mode | Fail Safe (NC) |
| Locking delay time | 0, 3, 6 and 9 seconds |
| Power Supply | DC 12 V / 960 mA máx. (start) / 180 mA max. (rest) |
| Retention force | 1000 kg |
| Mounting | Surface |
| Open sensor | LED indicator and door indicator output (integrated in socket) |
| Weight | 1.06 kg |
| Entrance profile | Narrow 25mm |
| Plate dimensions | 150 (H) x 25 (W) x 37 (D) mm |
| Temperature | -40º C ~ +60º C |
