DVR 5n1 X-Security - 4 CH analog (8Mpx) + 4 IP (8Mpx) - Audio over coaxial - 4K (7FPS) Recording Resolution - 2 CH facial recognition - 4 CH Human and vehicle recognition
  • Brand: X-Security
  • Product Code: XS-XVR6104S-4KL-FACE
  • Availability: In Stock
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.

DVR 5n1 X-Security - 4 CH analog (8Mpx) + 4 IP (8Mpx) - Audio over coaxial - 4K (7FPS) Recording Resolution - 2 CH facial recognition - 4 CH Human and vehicle recognition


  • X-Security
  • DVR 5n1
  • 4 CH video HDTVI/HDCVI/AHD/CVBS / 4+4 IP / 1 CH audio
  • H.265+ / H.265 / H.264+ / H.264
  • 8M Recording resolution (7FPS) 6M / (10FPS) 5M / (12FPS) 4K-N, / 4MP, 3MP(15fps) 4M-N / 1080P or 720P or 960H or D1 or CIF (25/30fps)
  • PTZ Control (RS485/Coaxial)
  • Audio over coaxial
  • HDMI Full HD, VGA & CVBS Outputs
  • 2 CH facial recognition
  • Human and Vehicle Recognition (Available for 4 CH coaxial video)
  • Compact size
  • Mouse
  • 2 USB Ports
  • Space for 1 HDD
  • POS functions



  • DVR 5 in 1 X-Security
  • Mouse
  • 12VDC Power supply

alt



Article
Brand X-SECURITY
Product Code XS-XVR6104S-4KL-FACE
General
Internal storage 1 SATA HDD 3.5" of up to 10 TB (not included)
Video format HDTVI / HDCVI / AHD / CVBS / IP
Hybrid configuration Up to 8 IP Channels (8Mpx), replacing all the BNC channels
Recording method Manual, programmed, motion detection, alarm
Remote Access Web browser (ActiveX), mobile phone application or PSS software
Video inputs 4 Channels BNC (HDTVI / HDCVI / AHD / CVBS)
Weight 1.1 Kg
Communication RS485 (PTZ) /2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet)
Video outputs 1 HDMI 4K, 1 VGA
Audio inputs 1 Channel RCA
Display Resolution HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
Video / audio compression H.265+ / H.265 / H.264+ / H.264
Audio outputs 1 Channel RCA
Total bandwidth 64 Mbps
Bidirectional audio Reusing the audio input/output
Power DC 12V / 2A
Extra Stream coding 960H(15FPS) / D1, CIF(25/30FPS)
Intelligent motion detection Up to 4 channels capable of classifying targets amongst humans and vehicles
Recording resolution 8M (7FPS) / 6M (10FPS) / 5M (12FPS) / 4K-N, 4MP, 3MP(15fps) / 4M-N or 1080P or 720P or 960H or D1 or CIF (25/30fps)
Main Stream coding 8M (7FPS) / 6MP(10FPS) / 5MP(12FPS) / 4K-N, 4MP, 3MP(15FPS) / 4M-N, 1080P, 720P, 960H, D1, CIF (25/30FPS)
Dimensions 48 (H) x 260 (W) x 238 (D) mm
video analysis IVS: Face detection / People and vehicle recognition / Line crossing / Intrusion
Simultaneous multifunction Pentaplex: Live, Recording, Playback, Backup and Remote Access
Alarm No
Facial recognition 1 live analogue face comparison channel
Backup USB / Network
