- Brand: Oem
- Product Code: INJ-POE-30W
- Availability: In Stock
To order and view prices you must register or login.
PoE injector - Input/Output RJ45 10/100/1000 Mbps - Power 30 W - Maximum distance 100 m - PoE/PoE+ IEEE802.3af/at - Stabilized and protected
Power injector over Ethernet up to 30 W (PoE +). Gigabit.
Fast and simple solution that allows remote power supply to a network device, for example to an IP camera, using the same cable that is used for the network connection. Simply connect the network cable to the RJ45 input of the injector together with the power supply of the injector, thus obtaining data flow and power supply voltage through the same Ethernet cable that will connect to the RJ45 output of the injector.
The Power over Ethernet (PoE / PoE +) power of this injector complies with IEEE 802.3af / at standards and self-regulates the power requirements of the powered device. Up to a maximum of 30 W per simple connection on a Cat 5E or higher UTP cable. It is useful up to a maximum distance of 100 meters (restricted by the data transmission), allowing to locate the power supplies of the installation in a single centralized point. Stable and safe thanks to different protections against surges, peaks of current or short circuits.
It allows data rates of 10/100 Mbps Half-Duplex and 100/1000 Mbps Full-Duplex.
| Article | |
| Brand | Oem |
| Product Code | INJ-POE-30W |
| OPERATING ENVIROMENT | |
| Operating temperature | 0º C - 40º C |
| General | |
| Power Supply | 30 W (Max. 46~52 VDC) |
| Maximum range | 100 meters |
| Interface | Input / Output RJ45 of 10/100Mbps |
| Dimensions | 165 (D) x 38.5 (H) x 62 (W) mm |
| PoE features | According to IEEE 802.3af/at |
