X-Security NVR for IP cameras | 16 CH video | Compression H.265+ | 16 PoE Channels | Maximum resolution 12 Mpx | HDMI 4K, HDMI Full HD and 2 VGA output | WEB, DSS/PSS, Smartphone and NVR
  • Brand: X-Security
  • Product Code: XS-NVR6416A-4K16P
  • Availability: Discontinued
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.

X-Security NVR for IP cameras | 16 CH video | Compression H.265+ | 16 PoE Channels | Maximum resolution 12 Mpx | HDMI 4K, HDMI Full HD and 2 VGA output | WEB, DSS/PSS, Smartphone and NVR


  • X-Security
  • NVR for IP cameras
  • 16 CH
  • Supported bandwidth 320Mbps
  • Maximum resolution 12 Megapixel
  • H.265+/H.265/H.264+/H.264
  • Intelligent functions: 14 CH Real-time facial recognition, 16 CH Perimeter Protection and 4 CH ANPR (on-camera analytics)
  • Resolution up to 8Mpx
  • PTZ Control
  • Alarms
  • Audio
  • HDMI 4K, HDMI Full HD and 2 VGA output
  • Space for 4 HDD
  • WEB, CMS and Smartphone interface
  • 16 PoE ports IEEE802.3af/at
  • ONVIF Compatible


  • X-SECURITY NVR
  • Mouse
  • Ethernet Cable
  • Power supply cable
  • User instructions
  • CD with manual and software


General
Internal storage 4 SATA HDD 3.5" of up to 10 TB (not included)
Inputs for IP cameras LAN port up to 16 channels
Power 100 ~ 240 VAC / 16.7W (without HDD) / 150W (with PoE)
Decoding Resolution 16-channel@1080P (30 fps)
IP compatible cameras X-Security (native protocol), ONVIF
Recording method Manual, programmed, motion detection, alarm
Remote Access Web browser (ActiveX), mobile phone application or PSS software
Weight 4.3 Kg (without HDD)
Communication 3xUSB Ports / 2 RJ45 10/100/1000M (Ethernet)
Video compression format H.265+ / H.265 / H.264+ / H.264 / MPEG4
Video outputs 1 HDMI 4K, 1 HDMI Full HD, 2 VGA
Audio inputs 1 RCA input
Display Resolution HDMI1: 3840×2160; 1920×1080; 1280×1024; 1280 × 720 VGA1: 1920×1080; 1280×1024; 1280×720 HDMI2/VGA2: 1920×1080
Audio outputs 2 RCA outputs
Total bandwidth 320 Mbps
Bidirectional audio Reusing the audio input
Intelligent functions Line Crossing, Intrusion, Abandoned Object, Face Detection, Heat Map
Alarms 16 Inputs / 6 Relay NO/NC
Recording resolution 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 1.3MP, 720p, D1
Dimensions 76 (H) x 440 (W) x 412.2 (D) mm
Power over Ethernet Up to 16 channels 150 W
Artificial intelligence Face recognition up to 14 CH, License plate reading up to 4 CH or Up to 16 CH of human and vehicle recognition in VCA rules. *On-camera analytics
Backup USB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA
