X-Security NVR for IP cameras - 16 CH IP video and 16 PoE ports - Maximum recording resolution 12 Mpx - 1 CH facial recognition - 2 CH human and vehicle recognition - Compression H.265+
  • Brand: X-Security
  • Product Code: XS-NVR3216A-4K16P-1FACE
  • Availability: Discontinued
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.

X-Security NVR for IP cameras - 16 CH IP video and 16 PoE ports - Maximum recording resolution 12 Mpx - 1 CH facial recognition - 2 CH human and vehicle recognition - Compression H.265+

  • X-Security
  • NVR for IP cameras
  • 16 CH
  • 80 Mbps bandwidth supported
  • Maximum resolution 12 Megapixel
  • 1 CH facial recognition
  • 2 CH perimeter protection with human and vehicle classification
  • Compression H.265+/H.265/H.264+/H.264/MJPEG
  • 16 PoE ports IEEE802.3af
  • VGA and HDMI 4K output
  • Alarms
  • Mouse
  • Space for 2 HDD
  • WEB, CMS (DSS/PSS), Smartphone and NVR interface
  • ONVIF Compatible
  • X-SECURITY NVR
  • Mouse
  • Adapter AC/DC 12 V / 1.5 A
  • User instructions
  • CD with manual and software

alt

Article
Brand X-Security
Product Code XS-NVR3216A-4K16P-1FACE
POWER
Power DC 12 V / 1.5 A / PoE IEEE802.3af
General
Inputs for IP cameras 16 channels
Video Compression H.265+/H.265/H.264+/H.264/MJPEG
Video outputs 1 HDMI 4K, 1 VGA
Input bandwidth 80 Mbps
Remote Access Web browser (ActiveX), mobile phone application or PSS software
Bidirectional audio 1 RCA input, 1 RCA output
Communication 2x USB 2.0 (Mouse and backup) /1 RJ45 10/100M (Ethernet)
Recording resolution 12Mp, 8Mp (on 1 channel), 6Mp, 5Mp, 4Mp, 3Mp, 1080P (on 4 channel), 720P, D1...
Intelligent motion detection Up to 2 channels capable of classifying targets amongst humans and vehicles
Recording method Manual, programmed, motion detection
Hard Disc 2 SATA HDD 3.5" of up to 8 TB (not included)
Simultaneous multifunction Pentaplex: Live, Recording, Playback, Backup and Remote Access
Alarm 4 IN / 2 Relay
Video analysis IVS: Line Crossing | Area Intrusion | Face Detection | Face Recognition
Facial recognition 1 live analogue face comparison channel
Backup USB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA internal interface
Weight 0.8 Kg (without HDD)
General Characterisitics
Dimensions 1U, 48 (H) x 260 (W) x 225 (D) mm
