DVR 5n1 X-Security - 16 CH HDTVI / HDCVI / AHD / CVBS / 16+2 IP - 1080N/720P (25FPS) | H.265+ - SMD+, enhanced motion detection - Two-way audio via RCA - Supports 1 hard disk up to 10TB

Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.

Description

Datasheet

Software

package contents

Specifications

Article
Brand	X-Security
Product Code	XS-XVR3116-HV
General
Internal storage	1 HDD SATA 3.5" of up to 10TB (not included)
Video format	HDTVI / HDCVI / AHD / CVBS / IP
Video inputs	16 Channels BNC (HDTVI / HDCVI / AHD / CVBS)
Video outputs	1 HDMI full HD and 1 VGA
Hybrid configuration	Up to 18 IP channels (6Mpx), (16 by substitution + 2 extra IP)
Remote Access	Web browser (ActiveX), mobile phone application or PSS software
Bidirectional audio	Reusing the audio input/output
Communication	RS485 (PTZ) /2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet)
Audio inputs	1 Channel RCA
Video / audio compression	H.265+/H.265/H.264+/H.264
Audio outputs	1 Channel RCA
Display resolution	1920x1080, 1280x1024, 1280x720
Power	DC 12 V / 2 A
Recording resolution	1080N; 720p; 960H; D1
Extra Stream coding	CIF (1~7 FPS)
Intelligent functions	POS Function \| Bidirectional Audio by RCA
Main Stream coding	First channel: 1080N, 720p (1~25/30FPS), Rest of channels: 1080N, 720p (1~15FPS) / 960H, D1,CIF (1~25/30 FPS)
SMD PLUS	Filter false alarms of people and vehicles in motion detection in 8 channels
Alarms	No
Recording method	Manual, programmed, motion detection (up to 396 zones)
Simultaneous multifunction	Pentaplex: Live, Recording, Playback, Backup and Remote Access
Dimensions / Weight	260.0 (W) × 237.9 (D) × 47.6 (H) mm / 1.042kg
Backup	USB (Memory, HDD, CD-RW, DVR-RW) / Network
